| Models |
- 7410 - Battery
- Long Range wireless output to receiver (up to 1000')
integrates with paging system (up to 1.5
miles)
- 7415 - Battery
- Long Range wireless output with Vandal
Trigger
- 7420 - Battery
- Local (internal) alarm
- 7425 -
Battery - Local (internal) alarm with
Vandal Trigger
- 7430 - Battery
- Short Range wireless output (20 - 50
ft)
- 7435 -
Battery - Short Range wireless output
with Vandal Trigger
- 7440 - 12 vDC
- Wired relay output (up to 5000 ft)
- 7445 - 12 vDC
- Wired relay output with Vandal Trigger
- 7450 - 12 vDC
- Local (internal) alarm and wired
relay output
- 7460 - ac 120
v - SMS Text Messaging
|
| Technical Information |
| |
|
- Diameter -
11 inches (28 cm)
- Height - 3.5 inches (9 cm)
- Weight - 2
lb ( 1.14 kg)
- Installation:
4 screws
|
|
- Four AA Batteries
- 12 vDC, 4.7
ma
- Output Relay
contact rating 3A
- Open collector
output
|
| |
- Coverage -
200 sq. ft.; 360 degrees Line of Sight
(LOS)
- Battery Life
- One Year
- Delays - 0
Sec or 30 sec
- Latch time
- 3 seconds or 30 seconds
- Alarm
volume (models 7420, 7425, 7450 only
- 85 dB
|
| Covered by US Patent 6,545,608
100% in-house tested before shipping |
